| Type |
1 + 8 passenger plane |
| Engine |
2 de Havilland Gipsy Six with 2-bladed fixed pitch propeller |
| Dimensions |
Length 10,52 m , height 3,12 m , span 14,63 m , wing area 31,2 m2 , aspect ratio 11,7, airfoil RAF 34 |
| Weights |
Empty 1465 kg, loaded 2495 kg, max. take off weight fuel 346 l , oil 16 l, cabin : length 4,1 m- height 1,4 m - width 1,2 m |
| Performance |
Max.. speed 253 km/h at 300 m 249 km/h at sea level , cruising speed 212 km/h , range 895 km, endurance , service ceiling 5100 m - 945 m with one engine and full payload , climb 4,40 m/sec. time to 1500 m 6 min. 45 sec., take-off run 265 m, landing run 155 m |
