| Type |
D-9 Single seat fighter |
D-12 Single seat fighter |
D-14 Single seat fighter |
| Engine |
1 Jumo 213 A-1 |
1 Jumo 213 E-1 |
1 DB 603 AE |
| Dimensions |
Length 10,13 m , height 3,35 m , span 10,50 m , wing area 18,30 m2, aspect ratio 6,02 , |
| Weights |
Empty 3249 kg, loaded 4270 kg , max. take off weight fuel 467 kg, oil 50 kg |
Empty 3269 kg, loaded 4400 kg , max. take off weight fuel 467 kg, oil 50 kg |
Empty 3440 kg, loaded 4351 kg , max. take off weight fuel 467 kg, oil 50 kg |
| Performance |
Max.. speed 686 km/h at 6600 m, cruising speed ,518 km/h at 6600 m range 810 km, endurance 1,33 h , service ceiling 11100 m , climb 16,0 m/sec., landing speed 167 km/h |
Max.. speed 725 km/h at 11000 m, cruising speed ,580 km/h at 8800 m range 750 km, endurance 1,25 h , service ceiling 12500 m , climb 17,0 m/sec., landing speed 170 km/h |
Max.. speed 710 km/h at 7400 m, cruising speed ,620 km/h at 7100 m range 800 km, endurance 1,25 h , service ceiling 11750 m , climb 16,0 m/sec., landing speed 170 km/h |
| Armament |
2 MG 131 fuselage, 2 MG 151 wings, 1 ETC 504 |
1 MK 108 engine, 2 MG 151 wings, 1 ETC 504 |
|
